Flutter for OpenHarmony垃圾分类指南App实战:答题挑战实现
摘要:答题挑战功能通过交互式测试帮助用户检验垃圾分类知识掌握程度。页面设计包含进度条、题目展示、选项和下一题按钮,采用响应式UI自动更新状态。核心逻辑包括:初始化答题状态、实时计算进度、动态生成选项、延迟跳转结果页等。通过视觉层次设计(如题号与题目样式区分)和状态控制(如答完自动跳转)提升用户体验,最终得分将展示在结果页面。

学了那么多垃圾分类知识,总得检验一下学习成果吧?答题挑战功能就是干这个的。用户可以通过答题来测试自己对垃圾分类的掌握程度,答对了有成就感,答错了也能学到新知识。
页面整体设计
答题页面的核心元素包括:顶部的进度条、题目内容、四个选项、以及底部的下一题按钮。整个流程是:显示题目 → 用户选择答案 → 显示对错 → 点击下一题 → 循环直到答完所有题目。
class QuizPage extends StatelessWidget {
const QuizPage({super.key});
Widget build(BuildContext context) {
// 获取答题相关的控制器
final controller = Get.find<GuideController>();
// 开始答题,重置状态
controller.startQuiz();
页面一进来就调用startQuiz()方法,这个方法会重置答题状态,比如当前题目索引归零、分数清零等。用StatelessWidget是因为所有状态都交给GuideController管理了。
为什么要在build方法里调用startQuiz()?这样每次进入答题页面都会重新开始,用户不会看到上次答题的残留状态。
响应式UI构建
整个页面用Obx包裹,这样当控制器里的状态变化时,UI会自动更新:
return Scaffold(
appBar: AppBar(
title: const Text('答题挑战'),
// 显示当前得分
actions: [
Center(
child: Padding(
padding: EdgeInsets.only(right: 16.w),
child: Obx(() => Text(
'得分: ${controller.quizScore.value}',
style: TextStyle(fontSize: 16.sp),
)),
),
),
],
),
body: Obx(() {
// 检查是否答完所有题目
if (controller.quizCompleted.value) {
// 使用addPostFrameCallback延迟导航
WidgetsBinding.instance.addPostFrameCallback((_) {
Get.offNamed(Routes.quizResult, arguments: controller.quizScore.value);
});
return const Center(child: CircularProgressIndicator());
}
这里有个小技巧:当所有题目答完后,需要跳转到结果页。但不能直接在build方法里调用导航,因为build方法可能会被多次调用,而且在build过程中修改状态是不允许的。所以用addPostFrameCallback把导航操作延迟到当前帧渲染完成后执行。
为什么用offNamed而不是toNamed?
offNamed会把当前页面从栈里移除,这样用户在结果页点返回时不会回到答题页,而是回到更上一级。这符合用户的预期——答完题就结束了,不需要再回到答题页。
获取当前题目数据
// 获取当前题目
final question = controller.questions[controller.currentQuestionIndex.value];
// 计算答题进度(0到1之间的小数)
final progress = (controller.currentQuestionIndex.value + 1) / controller.questions.length;
return Column(
children: [
// 进度条
_buildProgress(controller, progress),
// 题目和选项
Expanded(
child: Padding(
padding: EdgeInsets.all(20.w),
progress是个0到1之间的小数,表示答题进度。比如总共10题,当前是第3题,那progress就是0.3。这个值会传给进度条组件。
题目显示区域
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
// 题号
Text(
'第 ${controller.currentQuestionIndex.value + 1} 题 / 共 ${controller.questions.length} 题',
style: TextStyle(
fontSize: 14.sp,
color: Colors.grey,
),
),
SizedBox(height: 12.h),
// 题目内容
Text(
question['question'] as String,
style: TextStyle(
fontSize: 20.sp,
fontWeight: FontWeight.bold,
height: 1.5,
),
),
题号用灰色小字显示,题目内容用大号加粗字体,形成视觉层次。用户一眼就能看出哪个是主要内容。height: 1.5设置行高,让多行题目读起来更舒服。
选项列表生成
四个选项用List.generate动态生成:
SizedBox(height: 32.h),
// 生成四个选项
...List.generate(4, (index) {
return _buildOption(controller, index, question);
}),
],
),
),
),
// 下一题按钮(选择答案后才显示)
if (controller.showResult.value) _buildNextButton(controller),
],
);
}),
);
}
showResult控制下一题按钮的显示。用户选择答案后才会显示这个按钮,避免用户还没选就点下一题。
进度条组件
进度条让用户知道自己答了多少题,还剩多少:
Widget _buildProgress(GuideController controller, double progress) {
return Container(
padding: EdgeInsets.all(16.w),
decoration: BoxDecoration(
color: Colors.white,
boxShadow: [
BoxShadow(
color: Colors.black.withOpacity(0.05),
blurRadius: 4,
offset: const Offset(0, 2),
),
],
),
child: Column(
children: [
// 文字显示
Row(
mainAxisAlignment: MainAxisAlignment.spaceBetween,
children: [
Text(
'答题进度',
style: TextStyle(fontSize: 14.sp, color: Colors.grey),
),
Text(
'${(progress * 100).toInt()}%',
style: TextStyle(
fontSize: 14.sp,
color: AppTheme.primaryColor,
fontWeight: FontWeight.bold,
),
),
],
),
上面是文字显示"答题进度"和百分比,下面是可视化的进度条:
SizedBox(height: 8.h),
// 进度条
ClipRRect(
borderRadius: BorderRadius.circular(4.r),
child: LinearProgressIndicator(
value: progress,
backgroundColor: Colors.grey.shade200,
valueColor: AlwaysStoppedAnimation(AppTheme.primaryColor),
minHeight: 8.h,
),
),
],
),
);
}
用Flutter自带的LinearProgressIndicator实现进度条,ClipRRect给它加上圆角。minHeight设置进度条的高度。
选项按钮的实现
选项按钮是整个页面最复杂的部分,因为它有多种状态:未选中、已选中、答对、答错。
Widget _buildOption(
GuideController controller,
int index,
Map<String, dynamic> question,
) {
// 获取选项列表
final options = question['options'] as List<String>;
// 当前选项是否被选中
final isSelected = controller.selectedAnswer.value == index;
// 是否显示结果
final showResult = controller.showResult.value;
// 当前选项是否是正确答案
final isCorrect = question['answer'] == index;
先把需要的数据都准备好:选项列表、当前选项是否被选中、是否显示结果、当前选项是否是正确答案。
然后根据这些状态决定背景色和边框色:
// 默认样式
Color bgColor = Colors.white;
Color borderColor = Colors.grey.shade300;
Color textColor = Colors.black87;
if (showResult) {
// 显示结果时的样式
if (isCorrect) {
// 正确答案:绿色
bgColor = Colors.green.withOpacity(0.1);
borderColor = Colors.green;
textColor = Colors.green.shade700;
} else if (isSelected && !isCorrect) {
// 选错了:红色
bgColor = Colors.red.withOpacity(0.1);
borderColor = Colors.red;
textColor = Colors.red.shade700;
}
} else if (isSelected) {
// 选中但还没显示结果:主题色
bgColor = AppTheme.primaryColor.withOpacity(0.1);
borderColor = AppTheme.primaryColor;
textColor = AppTheme.primaryColor;
}
状态逻辑解释:
- 显示结果时,正确答案变绿色
- 显示结果时,如果用户选错了,选中的那个变红色
- 还没显示结果时,用户选中的选项变主题色
选项的UI结构
return GestureDetector(
// 只有在还没显示结果时才能点击
onTap: showResult ? null : () => controller.selectQuizAnswer(index),
child: Container(
width: double.infinity,
margin: EdgeInsets.only(bottom: 12.h),
padding: EdgeInsets.all(16.w),
decoration: BoxDecoration(
color: bgColor,
borderRadius: BorderRadius.circular(12.r),
border: Border.all(color: borderColor, width: 2),
),
用GestureDetector包裹整个Container,这样点击任何位置都能触发选择。边框宽度设为2,让选中状态更明显。showResult为true时,onTap设为null,禁止再次点击。
选项内部是字母标识和选项文字:
child: Row(
children: [
// 选项字母(A、B、C、D)
Container(
width: 32.w,
height: 32.w,
decoration: BoxDecoration(
shape: BoxShape.circle,
color: isSelected ? borderColor : Colors.grey.shade200,
),
child: Center(
child: Text(
// 把0、1、2、3转换成A、B、C、D
String.fromCharCode(65 + index),
style: TextStyle(
color: isSelected ? Colors.white : Colors.grey,
fontWeight: FontWeight.bold,
fontSize: 14.sp,
),
),
),
),
String.fromCharCode(65 + index)把0、1、2、3转换成A、B、C、D。65是字母A的ASCII码。
最后是选项文字和对错图标:
SizedBox(width: 12.w),
// 选项文字
Expanded(
child: Text(
options[index],
style: TextStyle(
fontSize: 16.sp,
color: textColor,
),
),
),
// 对错图标
if (showResult && isCorrect)
Icon(Icons.check_circle, color: Colors.green, size: 24.sp),
if (showResult && isSelected && !isCorrect)
Icon(Icons.cancel, color: Colors.red, size: 24.sp),
],
),
),
);
}
显示结果时,正确答案后面会出现绿色对勾,错误选择后面会出现红色叉号。这种即时反馈能帮助用户记住正确答案。
下一题按钮
Widget _buildNextButton(GuideController controller) {
// 判断是否是最后一题
final isLastQuestion = controller.currentQuestionIndex.value >=
controller.questions.length - 1;
return Container(
padding: EdgeInsets.all(16.w),
decoration: BoxDecoration(
color: Colors.white,
boxShadow: [
BoxShadow(
color: Colors.black.withOpacity(0.05),
blurRadius: 4,
offset: const Offset(0, -2),
),
],
),
child: SafeArea(
child: SizedBox(
width: double.infinity,
child: ElevatedButton(
onPressed: controller.nextQuestion,
style: ElevatedButton.styleFrom(
backgroundColor: AppTheme.primaryColor,
padding: EdgeInsets.symmetric(vertical: 16.h),
shape: RoundedRectangleBorder(
borderRadius: BorderRadius.circular(12.r),
),
),
child: Text(
isLastQuestion ? '查看结果' : '下一题',
style: TextStyle(
fontSize: 16.sp,
color: Colors.white,
fontWeight: FontWeight.bold,
),
),
),
),
),
);
}
按钮文字会根据是否是最后一题而变化。如果还有下一题就显示"下一题",如果是最后一题就显示"查看结果"。这种细节能让用户知道自己的进度。
SafeArea确保按钮不会被底部的安全区域遮挡(比如iPhone的Home Indicator)。
控制器的实现
class GuideController extends GetxController {
// 题目列表
final questions = <Map<String, dynamic>>[
{
'question': '塑料瓶属于什么垃圾?',
'options': ['可回收物', '有害垃圾', '厨余垃圾', '其他垃圾'],
'answer': 0,
},
{
'question': '废电池属于什么垃圾?',
'options': ['可回收物', '有害垃圾', '厨余垃圾', '其他垃圾'],
'answer': 1,
},
{
'question': '剩饭剩菜属于什么垃圾?',
'options': ['可回收物', '有害垃圾', '厨余垃圾', '其他垃圾'],
'answer': 2,
},
// ... 更多题目
];
// 当前题目索引
final currentQuestionIndex = 0.obs;
// 当前得分
final quizScore = 0.obs;
// 用户选择的答案(-1表示未选择)
final selectedAnswer = (-1).obs;
// 是否显示结果
final showResult = false.obs;
// 是否答完所有题目
final quizCompleted = false.obs;
/// 开始答题,重置所有状态
void startQuiz() {
currentQuestionIndex.value = 0;
quizScore.value = 0;
selectedAnswer.value = -1;
showResult.value = false;
quizCompleted.value = false;
}
/// 选择答案
void selectQuizAnswer(int index) {
// 如果已经显示结果,不允许再选择
if (showResult.value) return;
selectedAnswer.value = index;
showResult.value = true;
// 判断是否答对
final correctAnswer = questions[currentQuestionIndex.value]['answer'];
if (index == correctAnswer) {
quizScore.value += 10; // 每题10分
}
}
/// 下一题
void nextQuestion() {
if (currentQuestionIndex.value < questions.length - 1) {
// 还有下一题
currentQuestionIndex.value++;
selectedAnswer.value = -1;
showResult.value = false;
} else {
// 答完所有题目
quizCompleted.value = true;
}
}
}
题目数据的扩展
实际项目中,题目数据可以从后端获取:
Future<void> loadQuestions() async {
try {
final response = await dio.get('/api/quiz/questions');
questions.value = (response.data as List)
.map((json) => Question.fromJson(json))
.toList();
} catch (e) {
// 使用本地题库
questions.value = localQuestions;
}
}
也可以实现随机出题:
void startQuiz({int count = 10}) {
// 从题库中随机选择指定数量的题目
final shuffled = List.from(allQuestions)..shuffle();
questions.value = shuffled.take(count).toList();
// 重置状态
currentQuestionIndex.value = 0;
quizScore.value = 0;
// ...
}
答题功能是个很好的互动形式,既能检验学习效果,又能增加App的趣味性。实现起来主要是状态管理要理清楚,UI部分反而不难。
